12F Ferrule

Based on polyohenvlene sulfide (PPS) thermoplastic composite materials, FSG can produce various sinale-mode and multi-mode Ferrules with 2-48 cores, which can connect 80/125um optical fiber. The Ferrule is widely used in traditional 12F MPO connectors, and can also match the new 16F Key ofset MPO type. lt also supports customized development of passive or active optical fil ber component manufacturers. what is more, FSG provides MT Ferrules of various performance types, which can be customized according to specific applications and the number of diferent fiber channels.

0.7 mm Guide Hole Diameter, 4.6 mm Guide Hole Pitch

Product Features

福可喜玛福可喜玛

You can choose various type of single-mode, single-mode low loss multi-mode, multi-mode low loss, Pre-Angle Ferrule

福可喜玛福可喜玛

You can choose 0.7mm quide hole, 4.6mm quide hole pitch; 0.55mm quide hole, 5.3mm quide hole pitch

福可喜玛福可喜玛

2F-48F, hiah density. Optical fiber pitch: 0.25mm

福可喜玛福可喜玛

Operating temperature: from-40℃ to+75℃, extremely low moisture-absorbing material, excellent environmental stability

福可喜玛福可喜玛

It can be customized according to the application scenario

Product Applications

福可喜玛 福可喜玛

Data center, Multimedia, Telecommunications network, Industry

福可喜玛 福可喜玛

AOC cable, Multi-core optical fiber and FAN-OUT components

福可喜玛 福可喜玛

High-speed communication system

福可喜玛 福可喜玛

Customized high-precision module package

Product Specifications

Type 12F
Construction12F-MT
Pin Aperture/spacing12FT--MT
Dimension8*6.4*2.5mm
MM Std0.40(0.20)
MM LL0.25(0.12)
SM Std0.50(0.25)
SM LL0.35(0.15)
